OpenSky Flight Scraper: Live Aircraft Positions

Takes a snapshot of every aircraft currently transmitting inside a geographic box: ICAO24 address, callsign, origin country, latitude, longitude, barometric and geometric altitude, ground speed, heading and vertical rate.

The OpenSky Network is a community ADS-B receiver network that publishes its live state vectors over a plain HTTP API. This Actor calls that API directly, so there is no browser, no proxy, no login and no scraping of a rendered map. A box covering the Alps returns roughly 240 aircraft.

Agent skill: SKILL.md

https://api.apify.com/v2/key-value-stores/t7YoTxpZEJOWvw4Ug/records/opensky-flights-scraper.md

What you get

Field	What it holds
icao24	24-bit ICAO transponder address in lowercase hex, the stable aircraft identifier
callsign	Flight callsign as broadcast, trimmed. null when the aircraft is not transmitting one
originCountry	Country the transponder address is registered to
timePosition, timePositionIso	When the position fix was taken, as Unix seconds and ISO 8601
lastContact, lastContactIso	Last time any message was received from this aircraft
latitude, longitude	WGS84 position in decimal degrees
baroAltitude, geoAltitude	Barometric and geometric altitude in metres
onGround	Whether the network places the aircraft on a surface
velocity	Ground speed in metres per second
trueTrack	Track over ground in degrees clockwise from true north
verticalRate	Metres per second, positive climbing
squawk	Transponder code
spi	Special-purpose indicator flag
positionSource, positionSourceLabel	0 to 3 and its name: ADS-B, ASTERIX, MLAT or FLARM
snapshotAt	The single timestamp the whole snapshot belongs to
scrapedAt	Run timestamp

RUN_SUMMARY in the key-value store holds counts, whether the run was authenticated, the API credits left, the filters you used, and any request that failed.

Use cases

• Regional traffic monitoring. Schedule a run every few minutes over one box and build a time series.
• Airport apron analytics. A tight box plus onGroundOnly gives taxiing and parked aircraft.
• Fleet tracking. Pass a list of icao24 addresses and follow specific airframes.
• Live displays. Feed a map or dashboard with a current snapshot on demand.
• Aviation research. Sample altitude, speed and vertical-rate distributions over a corridor.

Quick start

Everything over the Alps:

{
 "boundingBox": { "lamin": 45, "lomin": 5, "lamax": 48, "lomax": 10 }
}

Aircraft on the ground around a UK box, capped:

{
 "boundingBox": { "lamin": 49.9, "lomin": -6.4, "lamax": 55.8, "lomax": 1.8 },
 "onGroundOnly": true,
 "maxResults": 200
}

Named airframes, authenticated for the higher quota:

{
 "icao24": ["4b4072", "3c6444"],
 "clientId": "your-opensky-client-id",
 "clientSecret": "your-opensky-client-secret"
}

Input

Field	Type	Default	Notes
boundingBox	object	none	{ lamin, lomin, lamax, lomax } in WGS84 degrees. Omit for a worldwide query, which costs 4 credits instead of 1.
icao24	array	[]	6-hex-character ICAO addresses. Batched 50 per request. Combines with boundingBox if both are set.
onGroundOnly	boolean	false	Keep only aircraft reported on a surface. Off returns airborne and grounded alike.
maxResults	integer	500	Cap on states saved, applied after filtering.
clientId	string (secret)	none	Optional OAuth2 client ID.
clientSecret	string (secret)	none	Optional OAuth2 client secret. Both must be present or the run stays anonymous.

boundingBox is validated before any request goes out: latitudes must be -90 to 90, longitudes -180 to 180, and lamin/lomin must be below lamax/lomax. An inverted or out-of-range box fails immediately rather than silently returning nothing.

Output example

{
 "icao24": "39de43",
 "callsign": "TVF99KE",
 "originCountry": "France",
 "timePosition": 1786016349,
 "timePositionIso": "2026-08-06T11:39:09.000Z",
 "lastContact": 1786016350,
 "lastContactIso": "2026-08-06T11:39:10.000Z",
 "longitude": 9.2508,
 "latitude": 45.3561,
 "baroAltitude": 11574.78,
 "geoAltitude": 12230.1,
 "onGround": false,
 "velocity": 220.77,
 "trueTrack": 288.9,
 "verticalRate": 0,
 "squawk": "5515",
 "spi": false,
 "positionSource": 0,
 "positionSourceLabel": "ADS-B",
 "snapshotAt": "2026-08-06T11:39:10.000Z",
 "scrapedAt": "2026-08-06T11:39:11.586Z"
}

Units are SI throughout: metres for altitude, metres per second for velocity and vertical rate, degrees for position and track. Nothing is converted to feet or knots, so convert on your side if you need to and no precision is lost here.

Credits and rate limits

OpenSky meters /states/all in credits, and the cost depends on how much sky you ask for:

Query	Credits
Box of 25 square degrees or less	1
Box up to 100 square degrees	2
Box up to 400 square degrees	3
Larger box or worldwide	4

Access	Daily credits	Snapshot resolution
Anonymous (by IP)	400	10 seconds
OAuth2 client credentials	4,000	5 seconds

Anonymous access is shared per source IP, and Apify runs go out through shared addresses, so the 400 you nominally get may already be partly spent. The Actor logs the x-rate-limit-remaining value OpenSky returns and stores it in RUN_SUMMARY.creditsRemaining, so you can see exactly where you stand after every run. If you plan to schedule this, register a free OpenSky account, create an API client, and paste the client ID and secret in. The Actor then fetches an OAuth2 token itself.

API example

curl -X POST "https://api.apify.com/v2/acts/arman-bd~opensky-flights-scraper/run-sync-get-dataset-items?token=YOUR_TOKEN" \
 -H "Content-Type: application/json" \
 -d '{
 "boundingBox": { "lamin": 45, "lomin": 5, "lamax": 48, "lomax": 10 },
 "maxResults": 100
 }'

JavaScript example

import { ApifyClient } from 'apify-client';

const client = new ApifyClient({ token: 'YOUR_TOKEN' });
const run = await client.actor('arman-bd/opensky-flights-scraper').call({
 boundingBox: { lamin: 49.9, lomin: -6.4, lamax: 55.8, lomax: 1.8 },
 maxResults: 500,
});

const { items } = await client.dataset(run.defaultDatasetId).listItems();
for (const state of items) {
 console.log(`${state.callsign ?? state.icao24} - ${state.baroAltitude} m at ${state.velocity} m/s`);
}

Notes

• One snapshot gets one timestamp. Every record in a run shares the same snapshotAt, so the dataset is a coherent instant rather than a smear.
• Positional arrays are decoded for you. The API returns each aircraft as a bare 17-element array, and the Actor maps it against the documented state-vector contract and hands you named fields.
• Nulls are real. baroAltitude, squawk, velocity and verticalRate are absent for many aircraft, and an aircraft on the ground usually has no barometric altitude. Those stay null rather than being coerced to zero.
• Duplicate addresses collapse. If the same icao24 appears twice in one snapshot only the first is saved.
• Transient errors get retried. 429 and 5xx responses get three attempts with linear backoff. A 401 or 403 is fatal, because it means credentials or quota, not a blip.
• Public data only. ADS-B is broadcast unencrypted by aircraft, and OpenSky aggregates it from volunteer receivers.

FAQ

Do I need an OpenSky account? No. You supply no credentials.

Why did I get zero aircraft? Either the box is over empty airspace or your IP's daily credits ran out. RUN_SUMMARY.creditsRemaining tells you which.

Can I get historical flights? No. This Actor reads the live state snapshot only. OpenSky's historical endpoints need an authenticated account and a different query model.

Are altitudes in feet? No, metres, exactly as the API delivers them. Multiply by 3.28084 for feet.

Why is callsign empty for some aircraft? Not every transponder broadcasts one, particularly general aviation and aircraft on the ground. icao24 is always present and is the field to key on.

Can I schedule it? Yes, and that is the point. A run every five minutes over one small box costs about 288 credits a day, which fits inside the anonymous allowance if the IP is not shared. Authenticate for anything tighter than that.
