Rag Vector Store Writer

Apify Actor that writes embedding vectors to Pinecone or Qdrant vector databases. Chains directly with RAG Embedding Generator output or accepts raw vectors with metadata. Handles batching, retries, collection creation, metadata mapping, and ID generation. Bring your own vector DB API key. MCP-ready for AI agent integration.

Features

• Two vector database providers: Pinecone and Qdrant Cloud
• Two input modes: dataset chaining (from RAG Embedding Generator) or raw vector JSON
• Pinecone: resolves index host via control plane, batched upserts (max 1000/batch), namespace support
• Qdrant: auto-creates collection if missing (with configurable distance metric), batched upserts
• Metadata pass-through: all non-embedding fields from input become metadata/payload in the vector DB
• Configurable vector ID field (default: chunk_id from RAG Content Chunker), UUID fallback
• Exponential backoff retry on rate limits and transient failures (3 attempts)
• API key marked isSecret -- never logged, never stored, never included in output
• Hardcoded API URLs and URL pattern validation to prevent SSRF attacks
• Input validation and sanitization (provider whitelist, index name regex, batch size limits)

Requirements

• Python 3.11+
• Apify platform account (for running as Actor)
• Pinecone or Qdrant Cloud API key and an existing index/cluster

Install dependencies:

$pip install -r requirements.txt

Configuration

Actor Inputs

Defined in .actor/INPUT_SCHEMA.json:

• api_key (string, required) -- your Pinecone or Qdrant API key. Marked isSecret
• provider (string, optional) -- "pinecone" (default) or "qdrant"
• index_name (string, required) -- Pinecone index name or Qdrant collection name. Qdrant collections are auto-created if they don't exist
• environment (string, optional) -- Qdrant Cloud cluster URL (e.g., https://xyz.us-east-1.aws.cloud.qdrant.io:6333). Required for Qdrant
• namespace (string, optional) -- Pinecone namespace. Leave empty for default namespace. Ignored for Qdrant
• distance_metric (string, optional) -- Distance metric for Qdrant collection creation: "Cosine" (default), "Dot", or "Euclid". Only used when auto-creating a new collection. Ignored for Pinecone
• dataset_id (string, optional) -- Apify dataset ID from RAG Embedding Generator. Items must have an embedding field. Takes priority over vectors
• vectors (array, optional) -- Direct vector input as JSON array. Each item needs an embedding field
• batch_size (integer, optional) -- Vectors per upsert request. Default: 100. Pinecone max: 1000, Qdrant max: 500
• id_field (string, optional) -- Field to use as vector ID. Default: "chunk_id". Falls back to UUID if missing

At least one of dataset_id or vectors must be provided, plus api_key and index_name.

Usage

Local (CLI)

$APIFY_TOKEN=your-token apify run

Pinecone -- Dataset Chaining

{
  "api_key": "pcsk_your-pinecone-key",
  "provider": "pinecone",
  "index_name": "my-rag-index",
  "namespace": "docs",
  "dataset_id": "abc123XYZ",
  "batch_size": 200
}

Qdrant -- Dataset Chaining

{
  "api_key": "your-qdrant-api-key",
  "provider": "qdrant",
  "index_name": "my-collection",
  "environment": "https://xyz-example.us-east-1.aws.cloud.qdrant.io:6333",
  "distance_metric": "Cosine",
  "dataset_id": "abc123XYZ"
}

Raw Vectors (Direct Input)

{
  "api_key": "pcsk_your-pinecone-key",
  "provider": "pinecone",
  "index_name": "my-index",
  "vectors": [
    {
      "chunk_id": "doc1-chunk0",
      "embedding": [0.0123, -0.0456, 0.0789],
      "source_url": "https://example.com/page",
      "page_title": "Example Page"
    },
    {
      "chunk_id": "doc1-chunk1",
      "embedding": [0.0321, -0.0654, 0.0987],
      "source_url": "https://example.com/page",
      "page_title": "Example Page"
    }
  ]
}

Example Output

A summary item is pushed to the default dataset:

{
  "_summary": true,
  "provider": "pinecone",
  "total_vectors_upserted": 42,
  "total_batches": 1,
  "processing_time": 2.341,
  "index_name": "my-rag-index",
  "namespace": "docs",
  "billing": {
    "total_vectors": 42,
    "amount": 0.0168,
    "rate_per_vector": 0.0004
  }
}

Pipeline Position

This actor fills the vector storage step in a standard RAG pipeline:

Crawl (Website Content Crawler, 101K+ users)
  -> Clean (optional preprocessing)
    -> Chunk (RAG Content Chunker)
      -> Embed (RAG Embedding Generator)
        -> Store (this actor)

Chaining with RAG Embedding Generator

1. Run RAG Content Chunker on your text or crawler output
2. Run RAG Embedding Generator with the chunker's output dataset ID
3. Copy the embedding generator's output dataset ID
4. Pass it as dataset_id to this actor
5. This actor reads each embedding, skips _summary rows, and upserts vectors with all metadata preserved

The full pipeline: crawl -> chunk -> embed -> store. Three dataset IDs passed between four actors.

Architecture

• src/agent/main.py -- Actor entry point, input routing (dataset/vectors), dataset loading, provider dispatch
• src/agent/validation.py -- Input validation, provider whitelist, index name regex, Qdrant URL pattern check (SSRF prevention), batch size limits
• src/agent/writers/pinecone.py -- Pinecone writer: host resolution via control plane, batched upserts, retry, metadata mapping
• src/agent/writers/qdrant.py -- Qdrant writer: collection auto-creation, batched upserts, retry, payload mapping
• src/agent/pricing.py -- PPE billing calculator ($0.0004/vector)
• skill.md -- Machine-readable skill contract for agent discovery

Security

• API key handling: Marked isSecret in input schema, validated for presence only, never logged or stored, stripped from error messages via _sanitize_error()
• SSRF prevention: Pinecone host resolved via hardcoded control plane URL (api.pinecone.io). Qdrant cluster URLs validated against strict cloud.qdrant.io pattern
• Provider whitelist: Only pinecone and qdrant accepted
• Input sanitization: Control characters stripped, index names and dataset IDs regex-validated, batch sizes bounded
• Error safety: All error messages pass through sanitization to prevent API key leakage
• No data retention: Vectors exist only in memory during the run

Pricing

Pay-Per-Event (PPE): $0.0004 per vector ($0.40 per 1,000 vectors).

This is the actor's platform fee only. You also pay the vector database provider (Pinecone or Qdrant) directly via your own account.

Content Size	Approx. Vectors	Actor Fee	Notes
Single blog post	10-20	$0.004-$0.008	Typical small doc
10-page website	50-100	$0.02-$0.04	Standard site
100-page docs site	500-1,000	$0.20-$0.40	Documentation portal
Large knowledge base	5,000-10,000	$2.00-$4.00	Enterprise scale

Troubleshooting

• "API key is required": Provide your Pinecone or Qdrant API key in the api_key field
• "Invalid provider": Must be "pinecone" or "qdrant"
• "Index/collection name is required": Provide the name of your Pinecone index or Qdrant collection
• "Invalid Qdrant cluster URL": Must match https://{cluster}.cloud.qdrant.io:6333 pattern
• "No input provided": Supply either dataset_id or vectors
• "API key is invalid or expired": Your provider key was rejected. Verify it in your Pinecone/Qdrant dashboard
• "Could not resolve host for Pinecone index": The index name doesn't exist in your Pinecone project
• "Failed after 3 attempts": Transient API error. Try again, or reduce batch_size
• "No items with valid 'embedding' arrays": Dataset items must have an embedding field with a non-empty float array

License

See LICENSE file for details.

---

MCP Integration

This actor works as an MCP tool through Apify's hosted MCP server. No custom server needed.

• Endpoint: https://mcp.apify.com?tools=labrat011/rag-vector-store-writer
• Auth: Authorization: Bearer <APIFY_TOKEN>
• Transport: Streamable HTTP
• Works with: Claude Desktop, Cursor, VS Code, Windsurf, Warp, Gemini CLI

Example MCP config (Claude Desktop / Cursor):

{
    "mcpServers": {
        "rag-vector-store-writer": {
            "url": "https://mcp.apify.com?tools=labrat011/rag-vector-store-writer",
            "headers": {
                "Authorization": "Bearer <APIFY_TOKEN>"
            }
        }
    }
}

AI agents can use this actor to write embedding vectors to Pinecone or Qdrant, build vector indexes, and populate RAG knowledge bases -- all as a callable MCP tool.
