Texas RRC Oil & Gas Well Permit (W-1) Scraper

Here is one real result, with every field the actor returns:

{
  "apiNumber": "47538447",
  "apiNumberFormatted": "475-38447",
  "district": "08",
  "rrcDistrict": "08",
  "leaseName": "MI DIA 48 WD1",
  "leaseNumber": "62302",
  "wellNumber": "901H",
  "operatorName": "XTO ENERGY INC.",
  "operatorNumber": "945936",
  "county": "WARD",
  "submittedDate": "07/18/2024",
  "approvedDate": "01/21/2025",
  "statusNumber": "881636",
  "wellboreProfile": "Horizontal",
  "filingPurpose": "New Drill",
  "amendment": true,
  "totalDepth": 10800,
  "stackedLateralParentDp": null,
  "status": "APPROVED",
  "universalDocNo": "497523671",
  "permitDetailUrl": "https://webapps2.rrc.texas.gov/EWA/drillingPermitDetailAction.do?methodToCall=searchByUniversalDocNo&universalDocNo=497523671",
  "leaseDetailUrl": "https://webapps2.rrc.texas.gov/EWA/leaseDetailAction.do?searchType=apiNo&apiNo=47538447&distCode=08&leaseNo=62302&methodToCall=displayLeaseDetail",
  "gisViewerUrl": "https://gis.rrc.texas.gov/GISViewer/index.html?api=47538447",
  "imagesUrl": "https://rrcsearch3.neubus.com/esd3-rrc/api.php?function=GetImage&api_no=47538447",
  "sourceUrl": "https://webapps2.rrc.texas.gov/EWA/drillingPermitsQueryAction.do",
  "issuedDate": "01/21/2025",
  "filedMethod": "Online",
  "wellStatusCode": "W - Final Completion",
  "spudDate": "11/12/2022",
  "drillingCompletedDate": "03/29/2023",
  "surfaceCasingDate": "11/13/2022",
  "completedWellType": "Oil Well",
  "completedDate": "03/29/2023",
  "validatedDate": "01/24/2025",
  "swr": "SWR 36, SWR 37",
  "distanceFromNearestTown": "4.0 miles",
  "directionFromNearestTown": "NE",
  "nearestTown": "Pecos",
  "surfaceLocationType": "Land",
  "gpsDatum": "NAD 83",
  "gpsX": "1321987.25",
  "gpsY": "10516620.43",
  "statePlaneZone": "Central",
  "section": "48",
  "block": "33",
  "survey": "H&TC RR CO / WHEAT, P H",
  "abstractNumber": "443",
  "permitRestrictions": "30 The designated interval for one or more of the fields approved in this permit appears to overlap with the designated interval of another field or fields in this district...",
  "leaseWellType": "Oil",
  "leaseFieldNumber": "71052900",
  "leaseFieldName": "PHANTOM (WOLFCAMP)",
  "currentOperatorStatus": "Active",
  "aiSummary": null,
  "aiRiskFlags": null,
  "aiTags": null
}

The most complete Texas oil and gas drilling permit scraper available. It returns every field the Railroad Commission W-1 Drilling Permit Query exposes (API number, operator, lease, field, county, RRC district, wellbore profile, total depth, status and dates), plus per-permit detail (spud, drilling-completed and surface-casing dates, completed well type, GPS coordinates, survey and legal location, permit restrictions) and lease summary (lease well type, field number and current operator status), and gives you 8 filters to target exactly the permits you need.

📥 Input · 📤 Output · 💰 Pricing · ▶️ Examples

Table of contents

• What it does
• Quickstart
• Input reference
• Output reference
• Example output record
• Run via API and CLI
• Fetch results
• Billing and limits
• FAQ and troubleshooting
• More scrapers at scrapers.lat

What it does

This actor searches the Texas Railroad Commission (RRC) public W-1 Drilling Permit Query and returns clean, structured permit records for landmen, mineral and royalty investors, and title shops. Every permit comes back with the operator, lease, field, county, RRC district, wellbore profile, total depth, permit status and the submitted and approved dates.

Turn on permit details and each record is enriched from the permit detail page with spud, drilling-completed and surface-casing dates, completed well type, SWR reference, surface location (nearest town, distance, direction), GPS coordinates and datum, survey and legal location (section, block, survey, abstract number) and any permit restrictions. Turn on lease summary to add the lease well type, field number and current operator status.

You can filter by operator name or number, county, RRC district, field name or number, lease name or number, API number, wellbore profile, and approved or submitted date ranges.

Quickstart

Run this input to pull recent horizontal permits approved in Ward County, District 08, with full permit details:

{
  "county": "WARD",
  "district": "08",
  "approvedDateFrom": "01/01/2025",
  "approvedDateTo": "01/31/2025",
  "maxItems": 100,
  "withDetails": true
}

Input reference

Name	Type	Required	Description	Example
operatorName	string	no	Permitted operator name, begins-with match	XTO ENERGY
operatorNumber	string	no	RRC operator (P-5) number	945936
county	string	no	Texas county name, mapped to RRC code automatically	WARD
countyCode	string	no	RRC 3-digit county code (overrides county name)	475
district	string	no	RRC district code	08
fieldName	string	no	Field name, begins-with match	PHANTOM (WOLFCAMP)
fieldNumber	string	no	RRC field number	71052900
leaseName	string	no	Lease name, begins-with match	MI DIA
leaseNumber	string	no	Oil lease or gas well ID number	62302
apiNumber	string	no	Look up a specific well by API number (digits only)	47538447
wellboreProfileCode	string	no	Wellbore profile code: V, H, D, S	H
approvedDateFrom	string	no	Permits approved on or after (MM/DD/YYYY)	01/01/2025
approvedDateTo	string	no	Permits approved on or before (MM/DD/YYYY)	01/31/2025
submittedDateFrom	string	no	Permits submitted on or after (MM/DD/YYYY)	01/01/2025
submittedDateTo	string	no	Permits submitted on or before (MM/DD/YYYY)	01/31/2025
maxItems	integer	no	Maximum permits to return (free accounts capped at 10)	100
withDetails	boolean	no	Fetch permit detail page (default true)	true
withLease	boolean	no	Fetch lease summary (default false, paid plans)	false
withAiSummary	boolean	no	Add an AI plain-English permit summary (default false)	false
withAiExtract	boolean	no	Add AI risk flags and tags (default false)	false
proxyConfiguration	object	no	Proxy settings (defaults to a stable US datacenter proxy)	{ "useApifyProxy": true }

Output reference

Name	Type	Description
apiNumber	string	Well API number, digits only
apiNumberFormatted	string	API number formatted with dash
district	string	RRC district code
rrcDistrict	string	RRC district code (normalized)
leaseName	string	Lease name
leaseNumber	string	Oil lease or gas well ID number
wellNumber	string	Well number
operatorName	string	Permitted operator name
operatorNumber	string	RRC operator (P-5) number
county	string	County name
submittedDate	string	Permit submitted date
approvedDate	string	Permit approved date
statusNumber	string	RRC status (tracking) number
wellboreProfile	string	Wellbore profile (Vertical, Horizontal, Directional)
filingPurpose	string	Filing purpose (New Drill, Recompletion, etc.)
amendment	boolean	Whether the permit is an amendment
totalDepth	integer	Total permitted depth in feet
stackedLateralParentDp	string	Stacked lateral parent well DP number
status	string	Permit status (APPROVED, etc.)
universalDocNo	string	RRC universal document number
permitDetailUrl	string	Link to the RRC permit detail page
leaseDetailUrl	string	Link to the RRC lease detail page
gisViewerUrl	string	Link to the RRC GIS map viewer for the well
imagesUrl	string	Link to scanned permit images
sourceUrl	string	Query source URL
issuedDate	string	Permit issued date (details)
filedMethod	string	Filing method, e.g. Online (details)
wellStatusCode	string	Completion well status code (details)
spudDate	string	Spud date (details)
drillingCompletedDate	string	Drilling completed date (details)
surfaceCasingDate	string	Surface casing date (details)
completedWellType	string	Completed well type, e.g. Oil Well (details)
completedDate	string	Completion date (details)
validatedDate	string	Validated date (details)
swr	string	Statewide Rule reference (details)
distanceFromNearestTown	string	Distance from nearest town (details)
directionFromNearestTown	string	Direction from nearest town (details)
nearestTown	string	Nearest town (details)
surfaceLocationType	string	Surface location type, e.g. Land (details)
gpsDatum	string	GPS datum, e.g. NAD 83 (details)
gpsX	string	Surface location X coordinate (details)
gpsY	string	Surface location Y coordinate (details)
statePlaneZone	string	State plane zone (details)
section	string	Survey section (details)
block	string	Survey block (details)
survey	string	Survey name (details)
abstractNumber	string	Abstract number (details)
permitRestrictions	string	Permit restrictions text (details)
leaseWellType	string	Lease well type (lease)
leaseFieldNumber	string	Lease field number (lease)
leaseFieldName	string	Lease field name (lease)
currentOperatorStatus	string	Current operator status, e.g. Active (lease)
aiSummary	string	AI plain-English summary (ai_summary)
aiRiskFlags	array	AI-extracted risk flags (ai_extract)
aiTags	array	AI-extracted keyword tags (ai_extract)

Example output record

See the real record at the top of this page. Fields marked (details), (lease) or (ai_*) populate only when the matching add-on is enabled.

Run via API and CLI

Start a run with the Apify API:

curl -X POST "https://api.apify.com/v2/acts/uefCpaPA5gzAkAgCP/runs?token=YOUR_APIFY_TOKEN" \
  -H "content-type: application/json" \
  -d '{"county":"WARD","district":"08","approvedDateFrom":"01/01/2025","approvedDateTo":"01/31/2025","maxItems":100}'

Or with the Apify CLI:

apify call scrapers_lat/texas-rrc-well-permits-scraper \
  --input '{"operatorName":"XTO ENERGY","maxItems":100}'

Fetch results

Download dataset items as JSON, CSV or Excel:

$curl "https://api.apify.com/v2/datasets/DATASET_ID/items?token=YOUR_APIFY_TOKEN&format=csv"

Billing and limits

This actor is pay per result. You are charged one result event per permit returned. Optional add-on events: details (permit detail enrichment, on by default), lease (lease summary), ai_summary and ai_extract. Add-on events are charged only when they return usable data, and paid add-ons are disabled for free Apify accounts. Free accounts are capped at 10 results per run. When you set a spend limit, the actor stops returning and charging once the limit is reached. Failed fetches are never charged.

FAQ and troubleshooting

Which permits are covered? Texas statewide W-1 drilling permits from the RRC Online Research Queries system, current and historical.

Do I get monthly production volumes? Not in this actor. It focuses on permits, well detail and lease summary. Monthly production volumes live in a separate RRC system.

Why are the detail fields null? They populate only when withDetails is on (default) and the permit detail page returns them.

County filter not applied? Use the exact county name (any case) or pass countyCode directly.

Nothing returned? Loosen your filters or widen the date range. Very broad searches are paginated automatically up to maxItems.
