Alphaliner Top 100 Carrier Fleet Scraper

Pulls the Alphaliner Top 100: the 100 largest container lines ranked by operated TEU, with the owned vs chartered split, orderbook, global market share and the full list of vessel IMO numbers in each carrier's fleet. One run reads the whole table in a single request.

This Actor reads structured data directly, so there's no browser, no proxy and no login required to use it.

Agent skill: SKILL.md

https://api.apify.com/v2/key-value-stores/t7YoTxpZEJOWvw4Ug/records/alphaliner-carrier-fleet-scraper.md

What you get

One record per carrier, ranked largest fleet first.

Field	What it holds
rank	Position by operated TEU, 1 (largest) to 100
operator	Full legal/registered operator name
carrierName	Brand/trading name (e.g. "MSC" for "Mediterranean Shg Co")
carrierCode	Short internal carrier code
companyId, companyRefId	Alphaliner's internal company identifiers
website	Carrier's schedule/website URL
flagIconUrl	Flag icon for the carrier's country of registration
notes	Free-text note (subsidiary brands folded into this operator, etc.), null when empty
totalTeu, totalShips	Total operated capacity: owned + chartered
ownedTeu, ownedShips	Owned-fleet portion
charteredTeu, charteredShips, charteredSharePercent	Chartered-in portion and its share of the total fleet
orderbookTeu, orderbookShips, orderbookSharePercent	Vessels on order and orderbook size as a percentage of the current fleet
marketSharePercent	Share of total global operated TEU
top30	true for the 30 largest operators
vesselImos	Every vessel's IMO number in that carrier's operated fleet
vesselCount	Length of vesselImos (populated even when the list itself is switched off)
globalFleet	Global cellular fleet totals (active vessels/TEU/DWT, transatlantic/transpacific/Europe trade capacity), the same object on every row
scrapedAt	Run timestamp

RUN_SUMMARY in the key-value store holds per-run counts, the filters you used, and any call that failed.

Use cases

• Carrier master data. vesselImos is a ready-made IMO-to-operator mapping for roughly 7,600 cellular ships, useful as a join key against AIS, port-call or sanctions data.
• Fleet strategy tracking. Compare ownedTeu vs charteredTeu over successive weekly runs to see which lines are growing owned tonnage vs leaning on the charter market.
• Orderbook and supply-side analysis. orderbookTeu and orderbookSharePercent show which operators are adding the most future capacity relative to their current fleet.
• Market concentration. marketSharePercent across all 100 rows gives a full HHI-style concentration picture of global container shipping.
• Credit and equity research. A clean, structured weekly snapshot instead of retyping the public table by hand.

Quick start

The full table, nothing filtered out:

{}

Just the carriers you care about, without the (large) IMO lists:

{
 "carriers": ["MSC", "Maersk", "CMA CGM", "COSCO"],
 "includeVesselImos": false
}

Only operators large enough to matter for a concentration study:

{
 "minTotalTeu": 500000,
 "maxCarriers": 30
}

Input

Field	Type	Default	Notes
carriers	array	[]	Keep only carriers whose operator or carrierName contains one of these terms (case-insensitive substring match). Empty means all 100.
minTotalTeu	integer	0	Drop carriers whose totalTeu is below this. 0 keeps everyone.
maxCarriers	integer	100	Stop after this many carriers, counted after the filters above. The table is pre-sorted by rank, so a lower value keeps the largest operators. Clamped to 1-100.
includeVesselImos	boolean	true	Populate vesselImos. Switch off for a much smaller dataset; vesselCount is still populated either way.
includeGlobalTotals	boolean	true	Attach globalFleet to every row. Switch off to get globalFleet: null and skip the extra request.

Nothing is required. Running with no input returns all 100 carriers, fully populated.

Output example

{
 "rank": 1,
 "operator": "Mediterranean Shg Co",
 "carrierName": "MSC",
 "carrierCode": "MSC",
 "companyId": "289",
 "companyRefId": "157581",
 "website": "https://www.msc.com/en/search-a-schedule",
 "flagIconUrl": "https://static.axsmarine.com/images/flags/big/ch.png",
 "notes": "MSC includes WEC Lines, Log-In Logistica",
 "totalTeu": 7389280,
 "totalShips": 1010,
 "ownedTeu": 4737110,
 "ownedShips": 759,
 "charteredTeu": 2652170,
 "charteredShips": 251,
 "charteredSharePercent": 35.9,
 "orderbookTeu": 2935318,
 "orderbookShips": 166,
 "orderbookSharePercent": 39.7,
 "marketSharePercent": 21.5,
 "top30": true,
 "vesselImos": ["9453298", "9463205", "9142447"],
 "vesselCount": 1010,
 "globalFleet": {
 "activeVessels": 7629,
 "activeTeu": 34594537,
 "activeDwt": 411462664,
 "fullyCellularVessels": 6812,
 "fullyCellularTeu": 34175555,
 "transatlanticTeu": 153697,
 "transpacificTeu": 601579,
 "europeTeu": 553910
 },
 "scrapedAt": "2026-08-21T12:00:00.000Z"
}

(vesselImos is truncated above for readability; a real record carries the full fleet.)

API example

curl -X POST "https://api.apify.com/v2/acts/arman-bd~alphaliner-carrier-fleet-scraper/run-sync-get-dataset-items?token=YOUR_TOKEN" \
 -H "Content-Type: application/json" \
 -d '{
 "minTotalTeu": 500000,
 "maxCarriers": 30
 }'

JavaScript example

import { ApifyClient } from 'apify-client';

const client = new ApifyClient({ token: 'YOUR_TOKEN' });
const run = await client.actor('arman-bd/alphaliner-carrier-fleet-scraper').call({
 carriers: ['MSC', 'Maersk'],
});

const { items } = await client.dataset(run.defaultDatasetId).listItems();
for (const c of items) console.log(`#${c.rank} ${c.carrierName}: ${c.totalTeu.toLocaleString()} TEU, ${c.vesselCount} ships`);

Notes

• The table has exactly 100 rows and no pagination: one run reads all of them in a single request.
• rank is derived from the table's own sort order (largest fleet first), not copied from the source's own rank field, which is only populated for the top 20 rows.
• globalFleet reflects the total active cellular container fleet, not just the Top 100. It is the same on every row in a given run because it is a single global figure, not a per-carrier one.
• notes sometimes lists subsidiary brands folded into the parent operator's Top 100 entry (for example, MSC's entry covers WEC Lines and Log-In Logistica too), which is useful context when reconciling against a brand-level list.
• This table is refreshed by its source on a weekly cadence, so daily runs will usually return identical or near-identical figures. A weekly schedule matches how often the numbers actually move.
• Attribute Alphaliner/AXSMarine as the source of this data; it is not licensed for resale as a bulk feed.

FAQ

Do I need an account or API key? No. No credentials are required to use this Actor.

How far back does this go? This is always the current snapshot. For history, run on a schedule (weekly matches the source's own update cadence) and key your own archive on scrapedAt.

Why is vesselCount sometimes different from totalShips? vesselCount counts the IMO numbers actually listed in the fleet string; totalShips is the source's own operated-ship count. They normally match; a handful of the smallest operators carry no vessel list at all, in which case vesselCount is 0.

Can I get owned and chartered fleets as separate vessel lists? No, vesselImos is the combined operated fleet. The owned/chartered split is only available as TEU and ship counts (ownedTeu/ownedShips vs charteredTeu/charteredShips), not per-vessel.

Does top30 change if I filter with carriers or minTotalTeu? No. top30 reflects the carrier's true rank in the full 100-row table, regardless of which rows your filters keep.

Can I plug it into something else? Yes. Apify API, the client libraries, webhooks, scheduled runs, dataset exports to JSON, CSV or Excel, or MCP. The output is structured JSON.
